| TECHNICAL SPECIFICATIONS | |
|---|---|
| Overall Length | 12500-13600 MM |
| Max Width | 2550 mm |
| Material | Chassis 4 mm Domex SSAB or 6 mm ST 52, with NPI 100 mm cross support beams / Chassis Welding: Arc submerged welding. |
| Container Twist Lock | (1X40", 2X20") |
| Flooring | Film faced Plywood or Chequered steel sheets 3-4 mm thickness. |
| Axles | 9, 12, 14 and 16 Ton available,, (DISK, DRUM) SAF, BPW and Turkish brands available |
| Suspension system | Air or Mechanic Suspension |
| Tires | 385/65 R22,5 / 445/65 R22.5 / 1200 R 24 and All sizes of tires available, Tires brand (BRIDGESTONE, LASSA,… etc) |
| Rims | Steel or aluminum rims 11,75 x 22,5 |
| Landing gears | 25 Ton Daynamic , 50 Ton Static - Double speed - JOST , SAF, OMS…. Etc |
| King - pin | SAE/DIN 2“ - 3,5 “ King-PİM |
| Break system | WABCCO EBS – ABS According to EU standard |
| Electric system | 24 volt / 2 x 7 + 15 pin plug socket, according to Directive 75/756/EEC ASPOCK ,SABA or SANEL with full led system according to EU standard |
| Side Guard | On the 2 sides - Made from aluminiuim profile according to the standard |
| Paint | sandblasting will be done firstly , then anti corrosion paint one layer epoxy ,then 2 layers of paint. |
| Accessories | 2 ECE R70 reflectors Side walls Reflective strips white, rear Panel Reflective strips red 1 x Plastic anti-slip wheel stopper 1 x Tool box 1 x food box Spare tire carrier for 2 tires Water tank – chrome fire extinguisher box |
