| DESIGN PARAMETERS | |
|---|---|
| Design Code | AD 2000 MERKBALTTER, EN 12493 ,EN 13445 ,ASME CODE and other codes |
| Capacity | ( 5 - 30 m3 ) |
| Body Type | Horizontal, Cylindrical |
| Heads Type | Elliptical or Hemispherical , Heat treatment 600 C º |
| Material | SA 516 Gr 70 / EN-10028.3 ( P355NH-P355NL1) / EN-10028.2 ( P355GH-P265GH) |
| Design Temperature | (-20 C° / +70 C°) |
| Design Pressure | 17,1 - 18 BAR |
| Test Pressure | 26,25 - 27.5 BAR |
| Welding | SAW -Submerged Arc Welding |
| Piping | SCH 40, SCH80 seamless pipes |
| Tests | UT (Ultrasonic Test ) - X-Ray : RT ( RadiographicTest ) - BT ( Beta Test ), Hydrostatic Test |
| Paint | Sandblasting will be done firstly, 2 layers of epoxy base paint, then 2 layers of paint . |
