| DESIGN PARAMETERS | |
|---|---|
| Design Code | AD 2000 MERKBALTTER, EN 12493, EN 13445, ASME CODE and other codes |
| Capacity | (0,5 m3 - 500 m3) According to request |
| Body Type | Horizontal, Cylindrical |
| Heads Type | Elliptical or Hemispherical, Heat treatment 600 C º |
| Material | SA 516 Gr 70 / EN-10028.3 (P355NH-P355NL1) / EN-10028.2 (P355GH-P265GH) |
| Design Temperature | (-20 C° / +70 C°) |
| Design Pressure | 17,1 - 18 BAR |
| Test Pressure | 26,25 - 27.5 BAR |
| Welding | SAW -Submerged Arc Welding |
| Tests | UT (Ultrasonic Test) - X-Ray :RT (RadiographicTest) - BT ( Beta Test), Hydrostatic Test |
| Paint | Sandblasting will be done firstly, 2 layers of epoxy base paint, then 2 layers of paint. |
