| DESIGN PARAMETERS | |
|---|---|
| Design Code | AD 2000 MERKBALTTER, EN 12493, EN 13445, ASME CODE and other codes |
| Capacity | (30 - 60 m3) According to request |
| Body Type | Horizontal, Cylindrical |
| Heads Type | Elliptical or Hemispherical, Heat treatment 600 C º |
| Material | SA 516 Gr 70 / EN-10028.3 (P355NH-P355NL1) / EN-10028.2 (P355GH-P265GH) |
| Design Temperature | (-20 C° / +70 C°) |
| Design Pressure | 17,1 - 22BAR |
| Test Pressure | 26,25 – 31,5 BAR |
| Welding | SAW -Submerged Arc Welding |
| Piping | SCH 40, SCH80 seamless pipes |
| Tests | UT (Ultrasonic Test) - X-Ray :RT (RadiographicTest) - BT (Beta Test), Hydrostatic Test |
| Paint | Sandblasting will be done firstly, 2 layers of epoxy base paint, then 2 layers of paint. |
| TECHNICAL SPECIFICATIONS | |
|---|---|
| Chassis | Carbon steel ST52 |
| Axles | 9, 12, 14 and 16 Ton available,(2 ,3 and 4 axle) available, (DISK, DRUM) available- SAF, BPW, Turkish brands available |
| Suspension System | Air Suspension, Mechanical Suspension and all other systems are available |
| Landing Gear | 25 Ton Dynamic , 50 Ton Static - 2 speeds - JOST , SAF, OMS…. Etc |
| Tires | 385/65 R22,5 , 1200 R 24 and all sizes of tires available, Tires Brands (BRIDGESTONE, LASSA,GOODYEAR etc …) |
| Rims | R22,5 - R24 |
| King-Pin | DIN Standard 2 ‘’, 3 " available |
| Brake System | According to standards ADR - WABCCO |
| Lighting System | According to standard (ADR) - SABA - SERTPLUS |
| Paint | Sandblasting will be done firstly, 2 layers of epoxy base paint, then 2 layers of paint . |
| Accessories of Chassis | Spare tire carrier, water tank, fire extinguisher, toolbox … etc |
